exam AUTOCAD
1. with ESC
A) deselected ENTITIES grips
B) ARE VALID ALL
C) END A COMMAND
D) CANCEL a context menu
2. THE RIGHT MOUSE BUTTON SERVE
A) ARE VALID ALL
B) HOW TO ENTER
C) TO REMOVE CONTEXTUAL MENUS
D) To call the last command executed
3. THE KEY IS TO DELETE
A) FOR NOTHING
B) DELETE OBJECTS
C) START AN ORDER
D) OUT OF ORDER
4. F3
A) activates FORZCOOR
B) ACTIVE oSnap
C) ACTIVE Orto
D) ACTIVE GRILLE
5. THE KEY F8
A) ACTIVE oSnap
B) is useless
C) ACTIVE Orto
D) activates the drain grill
6. TO DRAW LINES
A) FIRST introduce THE FIRST ITEM
B) FIRST introduce WHAT MEASURES
C) ASSETS Orto D) FIRST LINE I SELECT
7. THE VARIABLE LTSCALE
A) CONTROLS THE DRAWING LIMITS
B) CONTROLLING THE LAYERS
C) CHECKING SCALE TYPES OF LINE
D) CONTROL UNITS OF DRAWING
8. LAYERS
A) ARE JOINT ENTITIES CONFIGURABLE
B) ARE TO OPERATE THE COLOR OF WHAT draw
C) ARE TO MANAGE THE TYPE OF LINES
D) ARE A TYPE OF ENTITIES
9. COORDINATES DRESSES
A) HORIZONTAL ARE ALWAYS
B) they are always vertical
C) ARE ALIGNED WITH THE OBJECT TO REFINE
D) ARE ALWAYS OBLIQUE
10. IN ORDER EXTEND
A) FIRST I SELECT EXTEND TO WHERE I WANT
B) MAKING ENDS THE OBJECT TO ENLARGE
C) selected ALL INVOLVED ENTITIES
D) I NEVER CAN EXTEND ARCOS
11. HOW CAN WE ACCESS THE COMMANDS?
A) 3. FROM THE MENU BAR OR FROM THE TOOLS PALETTE
B) 4. 1 and 3 are correctly
C) 1. PRESSING THE ICONS OF THE TOOLBAR OR ENTERING COMMANDS directly from the keyboard
D) 2. ONLY USING THE TOOLS PALETTE
12. To draw a line at an angle of 45 degrees and a distance of 40 UNITS introduce WITH KEYBOARD
A) @ 40 <45
B) @ 45> 40
C) @ 45 <40
D)> 40 @ 45
13. DECOMPOSITION TOOL USED FOR
A) SEPARATE OBJECTS IN ONE COMPOUND AGRUPADOS
B) PARTIES TO ELIMINATE UNNECESSARY a complex figure
C) MODIFY THE VERTEX OF THE FIGURES
D) decomposing A SERIES OF COLORS
14. TO DEFINE A DEFAULT CIRCLE we WILL HAVE TO MARK
A) two tangents AND RADIO
B) THREE POINTS CIRCLE
C) CENTER AND RADIO
D) CENTER AND DIAMETER
15. TO MAKE A rectangular matrix we have to define
A) NUMBER OF COLUMNS AND ROWS AND THE DISTANCE BETWEEN THEM
B) NUMBER OF COLUMNS AND ROWS
C) CENTER POINT MATRIX
D) CENTER POINT MATRIX AND DISTANCE BETWEEN COLUMNS AND ROWS
in the previous video they could see the basics of management tools autocad
Autor
jorge nelson ochoa cardenas
andis andres cardenas guerrero
michael andres ospina tabares
